5′ x 6’7″ W-Style Double Ladder Scaffold Frame

5′ x 6’7″ W-Style Double Ladder Scaffold Frame

The 5′ x 6’7″ W-Style Double Ladder Scaffold Frame from USA Scaffolding is a Waco-style (W-Style) ladder frame with double ladder rungs for climbing from either side. Built from high-quality, non-recycled steel and powder-coated for long-lasting durability.

Specifications

• Dimensions: 5′ wide x 6’7″ tall
• Shipping Dimensions: 79″ L x 60″ W x 2″ H
• Frame Style: Waco (W-Style)
• Frame Type: Double Ladder — ladder rungs on both sides
• Frame Leg: 1-5/8″
• Wall Thickness: 0.090″
• Top Lock: 7″
• Lock Type: candy cane
• Drilled Hole: 90 degrees
• Finish: Powder Coat Red
• Weight: 49.59 lbs

Applications

The double ladder design allows climbing from either side of the scaffold, making it ideal for configurations where access is needed from multiple directions.

This frame requires 7′ x 4′ or 10′ x 4′ cross braces (CB7X4 or CB10X4).

Also Available as a Complete Set

This frame is also available as a complete 5′ x 6’7″ W-Style Double Ladder Scaffold Frame Set that includes:

• 2 — Waco Scaffold Frames (LFD56.7)
• 2 — Cross Braces
• 4 — Coupling Pins
• 4 — Spring Clips

At USA Scaffolding, our goal is to provide you with the highest quality product at the lowest possible price. Our scaffolding frames are heavy-duty and made with high-carbon steel so that they do not easily bend if dropped or if something runs into them. We also make our frames from virgin steel and not recycled steel like some of our low cost competitors do. Our scaffolding is designed to hold up on commercial projects, withstand large weight loads and hold up over the course of many jobs.

Stay Safe! Please refer to OSHA guidelines when erecting and using any construction scaffolding products. You can find general scaffolding safety requirements at https://www.osha.gov/etools/scaffolding/supported/frame
